Description
Model |
Rate Capacity ton |
Rated Speed m/min |
Wire Rope Capacity m |
Wire Rope |
Wire Rope Dia.mm |
Drum Center Height mm |
Motor Model |
Moter Power kw |
Brake Model |
Size mm |
Weight kg |
JM 3.2C |
3.2 |
16 |
160 |
6*37 |
15 |
315 |
Y160M-4 |
11 |
TJ2-200 |
1200*1040*575 |
630 |
JM 3.2 |
3.2 |
11 |
180 |
6*37 |
15 |
335 |
Y160M-6 |
7.5 |
TJ2-200 |
1215*1045*585 |
710 |
JM 3.2 |
3.2 |
11 |
180 |
6*37 |
15 |
335 |
YZR160M-6 |
7.5 |
TJ2-200 |
1230*1090*610 |
900 |
JM 3.2 |
3.2 |
16 |
180 |
6*37 |
15 |
335 |
Y160M-4 |
11 |
TJ2-200 |
1215*1045*585 |
710 |
JK 3.2 |
3.2 |
22 |
180 |
6*37 |
15 |
335 |
Y160M-4 |
15 |
TJ2-200 |
1215*1090*585 |
770 |
